Neuro protocol

Brain MRI

Brain MRI protocol with and without contrast for stroke/TIA, cancer, dementia, headache, hemorrhage, trauma, Chiari malformation, and selected contrast indications.

neurobrainstrokeTIAcancerdementiaheadachehemorrhagetraumaChiari malformationmultiple sclerosislesioninfectionwith and without contrast

For protocol planning and internal reference only. Follow institutional MRI safety screening, contrast, dosage, and GFR policies.

Full protocol variant

Routine Brain MRI

Variant switching updates protocol guidance while preserving shared routine Brain planning when no variant-specific planning is shown.

Decision supportContrast GuidanceDefault contrast approach and conditional indications.

Contrast indications

  • Metastatic disease
  • Tumor
  • Multiple sclerosis
  • Lesion
  • Infection

Dose notes

  • Contrast dose should follow institutional weight-based dosing policy.
Acquisition listSequencesRequired and conditional series for the exam.
SequencePlanePhaseRequiredNotes
Localizer Sagittal/Coronal/AxialAnynoncontrastYesCenter at the glabella.
Sagittal STIRsagittalnoncontrastYes-
Axial T2axialnoncontrastYes-
Axial FLAIRaxialnoncontrastYes-
Axial DiffusionaxialnoncontrastYesPrioritize DWI early when evaluating possible CVA in an uncooperative patient.
Coronal DiffusioncoronalnoncontrastYes-
Axial GREaxialnoncontrastYes-
Axial 3D T1axialprecontrastYes-
Axial 3D T1 +CaxialpostcontrastConditionalAcquire when contrast is indicated.
Coronal and Sagittal Reformats from Axial 3D T1 +Ccoronal and sagittalpostcontrastConditionalReformat axial 3D T1 postcontrast images in coronal and sagittal planes.
PositioningSlice PlanningPlane-specific planning instructions and guide images for technologists.

Brain protocol variants use shared routine Brain planning unless a variant-specific planning instruction is shown.

Localizer planning

  • Acquire sagittal, coronal, and axial localizers centered at the glabella.

sagittal

Sagittal planning

  • Cover the entire brain from left to right.
  • Cover from the top of the brain through the Foramen Magnum
  • Align parallel with the longitudinal fissure.

Brain sagittal planning

sagittal

Source slide: 2. Cropped planning image from BRAIN-CENTER TO GLABELLA / Sagittal.

axial

Axial planning

  • Cover the entire brain.
  • Align using the anterior and posterior aspect of the corpus callosum or use the AC-PC line, a line drawn from the upper surface of the Anterior Commissure (AC) horizontally to through the Posterior Commissure (PC) in sagittal view
  • Cover from the top of the skull through the foramen magnum.
  • For axial 3D T1 postcontrast imaging, include air above the scalp and extend inferiorly below the foramen magnum with balanced superior and inferior coverage.

Brain axial planning

axial

Source slide: 3. Cropped planning image from BRAIN / Axial.

coronal

Coronal planning

  • Cover the entire brain from anterior to posterior and side to side.
  • Align perpendicular to the axial slices.

Brain coronal planning

coronal

Source slide: 4. Cropped planning image from BRAIN / Coronal.

coronal and sagittal

Postcontrast reformat planning

  • Reformat axial 3D T1 postcontrast imaging in coronal and sagittal planes.
Anatomic extentCoverage RulesMinimum coverage expectations and alignment rules.

sagittal

Sagittal field of view

Cover the entire brain from left to right and from the top of the brain through C2.

sagittal

Sagittal alignment

Align parallel with the longitudinal fissure and ensure the midline slice passes through the aqueduct.

axial

Axial field of view

Cover the entire brain from the top of the skull through the foramen magnum.

axial

Axial alignment

Align using the inferior aspect of the horns of the corpus callosum.

axial

Postcontrast 3D T1 coverage

Include air above the scalp and extend below the foramen magnum with balanced superior and inferior coverage.

coronal

Coronal field of view

Cover the entire brain from anterior to posterior and side to side.

coronal

Coronal alignment

Align perpendicular to axial slices.

TechniqueSuggested Technique SpecificationsPlane-level vendor-neutral guidance from the source protocol.

sagittal

slice thickness
<= 5.0 mm
gap
<= 2.0 mm

axial

slice thickness
<= 5.0 mm
gap
<= 2.0 mm
axial 3d slice thickness
<= 1.0 mm
axial 3d voxel size
1.0 x 1.0 x 1.0 mm

coronal

slice thickness
<= 5.0 mm
gap
<= 2.0 mm

reformat

slice thickness
1.0 mm
gap
0 mm
Conditional workflowSpecial SituationsAdjustments for contrast, hardware, and protocol-specific conditions.

Contrast indicated

  • Add axial 3D T1 postcontrast sequence.
  • Reformat axial 3D T1 postcontrast images in coronal and sagittal planes.

Surgical hardware present

  • Remove fat saturation from FLAIR.

Uncooperative patient

  • Consider switching to a fast or BLADE brain protocol.
  • When evaluating possible CVA in an uncooperative patient, acquire DWI before other axial sequences.
